Both steel tumble belt and rubber tumble belt shot blasting machine is a small cleaning equipment. It mainly consists of cleaning chamber, blast wheel assembly, screw conveyor, elevator, separator, abrasive feeding system and dust collecting system.

The working principle of steel tumble belt shot blasting machine is that the specified number of workpieces are added into the blasting chamber. The door is closed. The machine is started and reverses. At the same time, the abrasvies thrown at high speed by the blast wheel form a fan beam,which is evenly hit on the surface of workpieces to clean. The thrown abrasives and sand particles flow from the holes of rubber belt into the screwconveyor at the bottom and are sent into the bucket elevator through screw conveyor, lifted into the separator by the elevator. The dusty air is sucked into the dust collector by the fan and filted to become clean air, which is discharged into the atmosphere. The dust is blown into the dust box at the bottom of the dust collector, and the user can periodically remove it.The wast sand is discharged from the wast pipe and can be reused by the user. The mixture of the abrasive and sand is recycled into the blasting chamber by the recycling tube, and reused afer separation by the separator. The layout of the blast wheel is simulated by the computer 3D design. The empty ejection is minimized, thereby maximizing the utilization of abrasives and reducing the wear on protective plates of blasting chamber.

28GN Steel Tumble Belt Shot Blasting Machine

15GN Steel Tumble Belt Shot Blasting Machine
