The Roller Conveyor Shot Blasting Machine for Aluminum Extruded Profiles is used to clean the surface of the aluminum profiles with defects, traces, delamination, non-metallic and metallic inclusions, corrosive spots and shells, craters and a trace after extrusion dies will be cleaned off. After mechanical sandblasting, the profiles will go into the anodizing line.
The scope of the shot blasting process:
1. Aesthetic finishing
2. Surface glazing
3. Removal of extrusion defects combined with chemical pickling
The Roller Conveyor Shot Blasting Machine for Aluminum Extruded Profiles is used to clean the surface of the aluminum profiles with defects, traces, delamination, non-metallic and metallic inclusions, corrosive spots and shells, craters and a trace after extrusion dies will be cleaned off. After mechanical sandblasting, the profiles will go into the anodizing line.
The scope of the shot blasting process:
1. Aesthetic finishing
2. Surface glazing
3. Removal of extrusion defects combined with chemical pickling
| Item | Q6910 | Q6912 | Q6915 | Q6920 | Q6925 | Q6930 | Q6940 |
| Effective cleaning width(mm) | 1000 | 1200 | 1500 | 2000 | 2500 | 3000 | 4000 |
| Opening size of machine inlet(mm) | 1000×260 | 1200×400 | 1500×400 | 2000×400 | 2500×800 | 3000×800 | 4000×4000 |
| Length of workpieces (mm) | 1200～12000 | 1200～12000 | 1200～6000 | 1200～12000 | 3000～12000 | 2400～12000 | 4500～18000 |
| Roller conveyor speed(m/min) | 0.5～4 | 0.5～4 | 0.5～4 | 0.5～4 | 0.5～4 | 0.5～4 | 2～8 |
| Thickness of steel plate(mm) | 4～60 | 4～60 | 4～60 | 4～60 | 4～60 | 4～110 | 4.5～100 |
| Blasting capacity(kg/min) | 4×250 | 4×250 | 4×250 | 4×250 | 6×250 | 6×360 | 8×360 |
| Initial feeding capacity(kg/min) | 4000 | 4000 | 4000 | 4500 | 4500 | 8000 | 11000 |
| Adjusting height of rolling brush(mm) | / | 200 | 350 | 450 | 600 | 850 | 900 |
| Ventilation capacity(m3/h) | 12000 | 17560 | 19000 | 19550 | 27758 | 28050 | 38000 |
| Total power(kw) | 78 | 78.3 | 113.5 | 156.6 | 224.55 | 204.8 | 293.6 |
1. Professional Sold Works design, optimized layout of blast wheel assembly.
2. Compact structure, high efficiency, good cleaning quality, safe and reliable work, stable operation.
3. Quality 10mm rolled Mn13 steel plate inside the blasting chamber prolongs service life of the liner, high wear resistance and impact resistance, good strength.
4. PLC automatic control.
